등록 단말간 직접 연결 통신 및 단말 릴레잉을 위한 디바이스 대 디바이스 링크의 HARQ 및 적응 전송 방법

단말간 직접 연결 통신 및 단말 릴레잉을 위한 디바이스 대 디바이스 링크의 HARQ 및 적응 전송 방법
이미지 확대
발명자
안재영, 노태균, 고영조
출원번호
13337646 (2011.12.27)
공개번호
20120163252 (2012.06.28)
등록번호
9014062 (2015.04.21)
출원국
미국
협약과제
11VI1100, 스마트 모바일 서비스를 위한 B4G 이동통신 기술 개발, 박남훈
초록
Provided is a method of processing hybrid automatic repeat request (HARQ) and adaptive transmission of a device-to-device (D2D) link. In the method, an operation method of user equipment (UE) includes (a) receiving an initial transmission mode (TM) and transmission power for the D2D link from a base station, and performing data transmission through the D2D link, (b) determining, at the UE, a TM and transmission power of a succeeding subframe, or receiving a TM control value and a transmission power control value from counterpart UE of the D2D link and determining the TM and the transmission power of the succeeding subframe, and (c) performing the data transmission to the counterpart UE using the determined TM and transmission power. Here, (b) and (c) are repeated.
KSP 제안 키워드
Adaptive Transmission, Automatic Repeat Request, Data transmission, Device to Device(D2D), Direct Communication, Hybrid automatic repeat request(HARQ), Link Adaptation(LA), Operation method, Power control(PC), Transmission mode, User equipment(UE), base station(BS), transmission power, transmission power control
