상세정보
등록 스마트 원격 노드의 구조 및 운용 방법
- 출원번호
- 15070778 (2016.03.15)
- 공개번호
- 20160277102 (2016.09.22)
- 등록번호
- 9755736 (2017.09.05)
- 출원국
- 미국
- 협약과제
- 14ZC2200, 지역광부품 고도화를 위한 광융합 기술개발, 이병탁
- 초록
- Disclosed is a smart remote node optical network node including an optical layer monitoring unit configured to transmit a monitoring light signal to an optical network unit through an optical switch and receive a monitoring light signal reflected from the optical network unit, an infra recognition unit configured to recognize whether an optical connector is connected to an output port of a remote node and an identification number of the optical connector when the optical connector is connected thereto, and a control unit connected to the optical layer monitoring unit and the infra recognition unit and configured to control recognition and monitoring operations of the remote node according to a remote node application.
- KSP 제안 키워드
- AND operation, Control Unit, Monitoring Unit, Network node, Operation method, Optical Connector, Optical layer, Optical network, Optical network unit(ONU), Optical switches, Remote Node
- 패밀리
| 구분 | 특허 | 출원국 | KIPRIS |
|---|---|---|---|
| 등록 | 스마트 리모트 노드 광통신 단말장치 및 그에 따른 리모트 노드 운용방법 | 대한민국 |
